Precision grinding machines with internal grinding equipment, and coolant system.
| Model | UG63 |
| Distance Between Centers | 2200/3120/4300/5300mm |
| Center Height | 335mm |
| Dia. Ground (O.D) | 30-630mm |
| Dia. Ground (I.D) | N/A |
| Max. Length Ground(O.D) | 2000/3000/4000/5000mm/td> |
| Max.Weight of Workpiece | 3000kg |
| Workhead |
|
| Workhead Swiveling Angle | Fixed |
| Center Taper | Metric #80 |
| Spindle Speed | 8-200 r/min |
| Wheelhead |
|
| Wheel Spindle Speed | 743r/min |
| Wheelhead Rapid Travel | 100mm |
| Max. Travel | 350mm |
| Swiveling Angle | Fixed |
| Hand Feed Per. Rev | Rough:2mm
Fine:0.5mm |
| Hand Feed Per. Gra | Rough:0.01mm
Fine:0.0025mm |
| Wheel Size（OD*W*ID) | 900 x 75 x 305mm |
| Peripheral Velocity | 35M/s |
| Internal Grinding Device |
|
| Spindle Speed | N/A |
| Dimension of Wheel | N/A |
| Table |
|
| Hand Feed Per. Rev | Fine 2mm, Rough 8mm |
| Longtiudinal Speed Range of Table | 0.1—3 M/min |
| Tailstock |
|
| Center Taper | Metric #80 |
| Quill Travel | 70mm |
| Motor |
|
| Wheelhead Motor Power | 22kw |
| Workhead Motor Power | 7.5kw |
| Oil Pump Motor Power | 3kw |
| Coolant Power | 0.25kw |
| Gross Weight | 19/23/25/28T |
| Packing Dimension | 7430/9783/12680/14178 x 3598 x 2185 mm |
Standard Accessories
• 3 Jaw Chuck
• Periperal Wheel Dresser
• Coolant System
• LED Light
• Grinding Wheel
• Open Type/Closed Steady Rest
• Balancing Stand and Arbor
• Extractor
• Drive Dog
• Centre
• Levelling Wedge
• Inverter Workhead
• Internal Grinding Attachment
• Wheel Dismount Tool
• Hydraulic Tailstock
• Front Guard With Interlock
• Wheel Lifter
• Hydrostatic Oil Tank For Spindle
• Measuring Plate
• Oil Tank
• Dial Gauge
• Wheel Lifter
• Wheel Dismount Tool
• Magnetic Filter System
Optional Accessories
• Magnetic Filter System
• 50L Paper Filter with Magnetic Separator and Coolant
• 100L Paper Filter with Magnetic Separator and Coolant
• 2 Axis DRO
• Radial Dresser
• End Dresser
• Half Center
• Internal Grinding Attachment
