- High Rigidity.
- Ball Screws and Linear Guideways.
- Window XP Based Control System, easily Compatible with Different Kinds of Software.
- Intelligent Database – Autocad Can Be Used Directly.
| Model | 3532WC | 3250WC | 4050WC | 5063WC | 6380WC |
| Table Travel | 250x320mm | 320x400mm | 400x500mm | 500x630mm | 630x800mm |
| Table Size | 380x525mm | 415x635mm | 600x900mm | 600x900mm | 660x1100mm |
| Max.Cutting Thickness | 300/500mm | 300/500mm | 500mm | 500mm | 500/800mm |
| Taper Angel(within thickness 100mm) | 0°/6°/60° | 0°/6°/60° | 0°/6°/60° | 0°/6°/60° | 0°/6°/60° |
| Roughness | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) |
| Precision | ≤0.015mm | ≤0.015mm | ≤0.015mm | ≤0.015mm | ≤0.015mm |
| Screw and Guide Way | High Quality Ball Screw; Linear Guideway | High Quality Ball Screw; Linear Guideway | High Quality Ball Screw; Linear Guideway | High Quality Ball Screw; Linear Guideway | High Quality Ball Screw; Linear Guideway |
| Load of Table | 300kg | 400kg | 500kg | 800kg | 3000kg |
| Machine Weight | 1600kg | 1700kg | 2000kg | 2300kg | 4500kg |
| Model | 80100WC | 100120WC | 100150WC | 130150WC | 160160WC | 120200WC |
| Table Travel | 800x1000mm | 1000x1200mm | 1000x1500mm | 1300x1500mm | 1600x1600mm | 1200x2000mm |
| Table Size | 820x1400mm | 1090x1600mm | 1090x1700mm | 1400x1900mm | 1950x1950mm | 1330x2440mm |
| Max.Cutting Thickness | 500/800mm | 500/800/1000mm | 500/800/1000mm | 500/800/1000mm | 500/800/1000mm | 500/800/1000mm |
| Taper Angel(within thickness 100mm) | 0°/6°/60° | 0°/6°/60° | 0°/6° | 0°/6° | 0°/6° | 0°/6° |
| Roughness | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) | Ra≤2.5μm Ra≤1.5μm (multi-cutting) |
| Precision | ≤0.015mm | ≤0.02mm | ≤0.02mm | ≤0.02mm | ≤0.02mm | ≤0.02mm |
| Screw and Guide Way | High Quality Ball Screw;
Linear Guideway | High Quality Ball Screw;
Linear Guideway | High Quality Ball Screw;
Linear Guideway | High Quality Ball Screw;
Linear Guideway | High Quality Ball Screw;
Linear Guideway | High Quality Ball Screw;
Linear Guideway |
| Load of Table | 5000kg | 6000kg | 6000kg | 6000kg | 6000kg | 6000kg |
| Machine Weight | 6700kg | 7000kg | 7500kg | 7800kg | 10000kg | 12000kg |
Standard Accessories:
• Digital Read Out
• Controller
• Normal Wire Tension System.
• High Precision Linear Guideway
• U.S.A Emerson Converter
• Central Lubrication System
• Coolant
• Remote Jog Handle
• Three Layer Filter Coolant System
• Reusable Molybdenum Wire
• Z Axis Automatic Move
Optional Accessories:
• Aluminium Cutting Device
