• Driven by hydraulic power, with variable speed
• High Pressure Chip Flushing System
• Automatic Cycling, Semi Automatic
• Cycling and Segmented Cycling available
• Centralised Lubrication
| Model | HBR20 |
| Rated Pulling Force | 200kn |
| Max.Stroke Length | 1600mm |
| Length Range of Broaching Tool | 600-1650mm |
| Hole Diameter of Worktable | 130mm |
| Max. Outer Diameter of Workpiece | 620mm |
| Working Speed | 1.5-11m/min |
| Returning Speed | 7-20m/min |
| Motor | 22kw(29.92hp) |
| Verticality Of Center Line Of Broach Rear Hole on Tested Workpiece Against Base | 0.06/200mm |
| Overall Dimensions | 6830x1820x1440mm |
| Net Weight | 5900kg |
Standard Acessories
• Tool Chuck
• Auxiliary Tool Chuck
• Faceplate
• Hydraulic Station
• Lubrication System
• Cooling Pump
• Chip-removal System
Optional Accessories
• Oil Cooler
• Air Spray Gun
• Broaching Tool
• Automatic Chip Conveyor (with chip trolley)
